know your stuff

Don’t worry! we have’nt gone anywhere. earlco steam-sauna is kzn’s most trusted supplier of steam room, sauna and spa accessories, heaters and boilers. we supply steam generators anywhere in south africa, and we repair and maintain steam generators all around KZN. We also supply sauna heaters, and we offer repairs and maintenance on them as well.

Below are the specs to each machine, so you can find exactly what it is you need!

a steam room is a sealed space filled with steam, creating a highly humid environment. using a steam room is a beneficial way to relax your muscles, revitalise your skin, raise your metabolism, improve blood circulation, relieve joint pains, and clear the sinuses. These are just the most well-known and proven benefits to using a steam room.

take a look at the various size machines we offer, and their respective room-sizes.

rated for a room no larger than 4 cubic meters.

single or three-phase power unit requires a single steam nozzle.

rated for a room no larger than 6 cubic meters.

three-phase power unit requires two steam nozzles.

rated for a room no larger than 8 cubic meters.

three-phase power unit requires two steam nozzles.

rated for a room no larger than 10 cubic meters.

three-phase power unit requires two steam nozzles.

in order to proceed with the installation of your machine, a few things will be required. correct preparations have to be made prior to the installation of the unit.

To install the unit, you will need the following:

I. A 15mm copper pipe will be required for a cold water supply.

II. A single or three-phase power supply is required.

III. The machine is to be mounted in a dry, well-ventilated area, outside or near the steam room.

iv. A drain is required near the machine, as the generator itself has to be drained on a regular basis, for maintenance and longevity reasons.

v. a 22mm copper pipe will be required to deliver steam from the generator to the room. a steam nozzle will be fitted over the pipe.

Units are to be drained on a weekly basis to prevent build-up of sediment inside the tank, and to prolong the lifespan of your elements. we recommend draining the machine once a week for domestic installations, and daily for commercial installations.

constructing a steam room entails a couple steps. all these steps are vital to the integrity of the room.

• steam rooms are built using concrete, brick, and cement, with waterproofing done, prior to tiling.

• seating should be wide and comfortable, with upper level and lower level seating where possible.
• the glass door must have a watertight seal around the sides and at the top.
• the recommended height for the ceiling is 2,2m from the floor, and must be waterproof, and should have a slight slope for condensation runoff.
• steam room lighting should be low-voltage, waterproof, and non-conductive. we recommend led strips.
• a floor drain must be installed, inside the steam room.
• the steam generator must be installed outside the steam room, in a dry, well-ventilated area.
• the steam generator can be installed in a ceiling, but the unit must be easily accessible, for maintenance and repair purposes.
• pvc piping is required from the location of the temperature sensor to the location of the control panel, to the location of the steam generator.


BELOW YOU CAN FIND LINKS TO OUR VARIOUS SPECIFICATION SHEETS.

INDUSTRIAL, COMMERCIAL, RESIDENTIAL.
